• TP-LINK (DR3650v-4G) Omada 4G+ Cat6 AX3000 Wi-Fi 6 Gigabit Desktop DSL Gateway, 4G+ Cat6 up to 300Mbps, VDSL2 35b, USB, VoIP Support, Centralized Management, Mesh Tech
1 7

TP-LINK

TP-LINK (DR3650v-4G) Omada 4G+ Cat6 AX3000 Wi-Fi 6 Gigabit Desktop DSL Gateway, 4G+ Cat6 up to 300Mbps, VDSL2 35b, USB, VoIP Support, Centralized Management, Mesh Tech

TP-LINK (DR3650v-4G) Omada 4G+ Cat6 AX3000 Wi-Fi 6 Gigabit Desktop DSL Gateway, 4G+ Cat6 up to 300Mbps, VDSL2 35b, USB, VoIP Support, Centralized Management, Mesh Tech

SKU: DR3650V-4G
£390.32
£390.32
Sale Sold out
Shipping calculated at checkout.



Omada 4G+ Cat6 AX3000 Wi-Fi 6 Gigabit Desktop DSL Gateway

  • AX3000 WiFi 6 with 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
  • 4G+ Cat6 up to 300Mbps
  • 3x RJ11 Ports (2x FXS, 1x DSL) & 5x RJ45 Gigabit Ports & 1x USB 3.0 Port
  • 2x Nano SIM for 4G/LTE Failover
  • VDSL2 35b: Supports 350Mbps DSL Access
  • VDSL2/ADSL2+/ADSL2/ADSL Compatibility
  • IPSec/PPTP/L2TP/OpenVPN/WireGuard/GRE/SSL VPN
  • Load Balancing Across DSL, 4G, and Ethernet WAN for Optimized Connectivity
  • Centralized Cloud Management
  • Desktop/Wall/Rack Mounting (Purchase Rackmount Kit-D226 Separately)





Get the Higher DSL Speeds Cost-Effectively

The integrated DSL port supports VDSL2/ADSL2+/ADSL2/ADSL connections. Compatibility with the leading ISPs provides ideal IP-based connections for any small business.





Versatile Connectivity

DR3650v-4G’s compatible with Super VDSL (VDSL2 Profile 35b), Ethernet access, and 4G/3G USB modems. Its Gigabit LAN/WAN port accepts connections from cable or fiber modems, and the FXS ports supports VoIP for reliable voice communication. The USB 3.0 port supports 4G/3G dongles for a solid main or backup internet connection.





Up to 3.0 Gbps Business-Level WiFi 6 Empowers Small and Medium Business
  • HE 160 - Double the data at peak transmission times on a single stream.
  • OFDMA - Enables different devices to share one transmission stream, increasing efficiency.
  • 1024 QAM - 25% more data encoded at one time.




Software Defined Networking (SDN) with Cloud Access

Centralized cloud management for Omada gateways, switches, and access points across multiple sites, with the Omada cloud-based controller offering the Essentials version of cloud services for free, reducing maintaince costs.





High-Security and High-Performance VPN

SSL/ IPSec / GRE / WireGuard / PPTP / L2TP VPN & OpenVPN easily build secure VPN tunnels for secure Internet browsing, communication between different branches, or enabling remote work or study from home.








Description

Specification

  • Type: VDSL2/ADSL2 Router
  • Connectivity: Wireless
  • Wi-Fi Rating: AX3000
  • Max Single Band Wi-Fi Rate: 2402 Mbps
  • Max Wired Transfer Rate: 10/100/1000 Mbps
  • Bands: Dual Band
  • Signal Rate: 5 GHz: 2402 Mbps
    2.4 GHz: 574 Mbps
    4G+ Cat6 up to 300Mbps
  • Interface(s): 1 x Gigabit WAN/LAN Port
    4 x Gigabit LAN Ports
    1 x DSL Port
    2 x FXS Ports
    1 x USB 3.0 (supports USB LTE dongle and USB Storage)
    Dual Nano SIM Slot (4G+ Cat6)
  • Frequency: 2.4 GHz & 5 GHz
  • Button(s): Reset Button
  • Power Supply: 12V DC / 3.3A Power Adapter

    Max Power Consumption:
    Power adapter not included: 28.482 W (Full load + USB)
    Power adapter included: 31.42 W (Full load + USB)
  • Antenna(s): Wi-Fi: 3x 5GHz 5dBi & 2.4GHz 3.5dBi dual-band detachable antennas
    LTE: 2x 4.0dBi omnidirectional detachable antennas
  • Dimensions: (WxDxH) 226 x 131 x 35 mm) (Antenna dimensions are not
    included)
  • Wireless Functions: Seamless Roaming
    Mesh (with EAP that supports Mesh)
    OFDMA
    Beamforming
    Enable/Disable SSID Broadcast
    Enable/Disable Wireless Radio
    MU-MIMO
    Load Balance
    Automatic Channel Selection Algorithm
    Airtime Fairness
    Rate Limit: Based on SSID/Client
    Transmit Power Control: Adjust transmit Power on dBm
    Multiple SSIDs: 16 in total (8 per radio)
    Guest Network
  • Security: "WiFi Encryption:
    WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise

    Access Control:
    Source/Destination IP Based Access Control

    Filtering:
    Web Group Filtering
    URL Filtering
    Web Security

    ARP Inspection:
    Sending GARP Packets
    ARP Scanning
    IP-MAC Binding

    Attack Defense:
    TCP/UDP/ICMP Flood Defense
    Block TCP Scan (Stealth FIN/Xmas/Null)
    Block Ping from WAN"
  • DHCP: DHCP Server
    DHCPv6 PD Server (only in Standalone Mode)
    DHCP Options Customization
    DHCP Address Reservation
    Multi-IP Interfaces
    Multi-Net DHCP
  • Port/NAT Forwarding: "66 Byte Packet Forwarding Rate:
    1,453,489 pps / 1,453,488 pps

    1,518 Byte Packet forwarding rate:
    81,274 pps / 91,275 pps"
  • VPN Support: "GRE:
    Only in Standalone Mode

    SSL VPN:
    50 Tunnels

    IPsec VPN:
    100 IPSec VPN Tunnels
    LAN-to-LAN, Client-to-LAN
    Main, Aggressive Negotiation Mode
    DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
    IPsec Failover
    IKE v1/v2
    MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
    NAT Traversal (NAT-T)
    Dead Peer Detection (DPD)
    Perfect Forward Secrecy (PFS)

    "
  • .: PPTP VPN:
    PPTP VPN Server
    PPTP VPN Client (10)
    50 Tunnels
    PPTP with MPPE Encryption

    L2TP VPN:
    L2TP VPN Server
    L2TP VPN Client (10)
    50 Tunnels
    L2TP over IPSec

    OpenVPN:
    OpenVPN Server
    OpenVPN Client (5)
    55 OpenVPN Tunnels
    ""Certificate + Account"" Mode
    Full Mode

    WireGuard VPN:
    Yes
  • Management: Omada App
    Centralized Management
    Cloud Access
    Zero-Touch Provisioning

    Maintenance:
    Web Management Interface
    Remote Management
    Export & Import Configuration
    SNMP v1/v2c/v3
    Diagnostics (Ping & Traceroute)
    NTP Synchronize
    Port Mirroring
    CLI (only in Standalone Mode)
    Syslog Support
    TR-069 (data models of TR-098 and TR181 are supported)

  • .: Management Features:
    Automatic Device Discovery
    Intelligent Network Monitoring
    Abnormal Event Warnings
    Unified Configuration
    Reboot Schedule
    Captive Portal Configuration
  • Dynamic DNS: "Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization"
  • USB Application: Supports USB LTE dongle and USB Storage
  • Additional Features: Flash: 256 MB NAND
    DRAM: 512 MB DDR4
    Desktop/Wall-mounting (Purchase Rackmount Kit Separately)
  • Environment: Operating Temperature: 0C°~40°C (32°F ~104°F)
    Storage Temperature: -40°C to 70°C (-40 °F to 158 °F)
    Operating Humidity: 10% to 90% non-condensing
    Storage Humidity: 5% to 90% non-condensing
  • Package Contents: "DR3650v-4G
    Power Adapter
    Ethernet Cable
    Phone Cable
    Rubber Feet,
    SIM Card Eject Pin
    Quick Installation Guide"
  • Package Type: Retail
  • Package Weight: 1.6500 kg
  • Warranty: Limited Lifetime
  • #Hide#Wireless Standard: Wi-Fi 6/6E (802.11ax)
  • #Hide#Mesh Wi-Fi Support: Yes (Mesh Wi-Fi)
