Tri-band WiFi 7 (802.11be) Mesh Router, 18 Gbps, Coverage Up to 6000 sq. ft. (2pk), Dual 10G ports, Smart Home Master SSIDs for IoT, VPN and parental controls, Commercial-grade security, Smart AiMesh

Blazing-fast tri-band WiFi 7 speeds of up to 18 Gbps with superior 6 GHz WiFi, Multi-Link Operation (MLO) and 4K-QAM.
AI-powered Smart AiMesh boosts coverage of up to 6000 sq. ft. (2pk) with faster, more stable connections and a powerful extendable network.
Eight internal antennas and ten high-power front-end modules eliminate WiFi dead zones in all directions.
Bolster your network capacity with dual 10G WAN and LAN Ethernet ports.
Versatile WAN configuration options with automatic WAN detection, and 4G LTE and 5G Mobile Tethering for always-on Internet.
Enjoy end-to-end protection with commercial-grade AiProtection Pro, advanced parental controls and comprehensive VPNs.
Establish up to three SSIDs with Smart Home Master Network for easy IoT device setup, convenient parental controls and instant VPN connections.

Worry-Free Smart Home Mesh

The ASUS ZenWiFi series advances your ever-evolving smart home with worry-free WiFi. The ASUS ZenWiFi BT10 raises the bar for whole-home mesh with WiFi 7 and next-gen Smart AiMesh technology. It delivers blazing-fast tri-band speeds up to 18 Gbps and unleashes superior 6 GHz WiFi. Along with ultra-high-speed dual 10 Gigabit Ethernet and a suite of advanced network and security technologies, this mesh WiFi system is ready to future-proof your smart home network today.

The Pinnacle of WiFi

ASUS ZenWiFi BT10 embodies our unwavering commitment to developing incredible in-house WiFi and network technologies. Seamlessly connect to your family and friends within a worry-free connected experience.

WiFi 7 Powering Premium Mesh

The ZenWiFi BT10 boasts cutting-edge WiFi 7 technology. This superior tri-band mesh system unleashes the full potential of WiFi 7 with wired backhaul options. Enjoy a next-generation connected experience for home entertainment and cloud computing, including 8K streaming, HDR gaming, content creation and AI.

Superior 6 GHz WiFi

Boasting a superior 6 GHz band, ZenWiFi BT10 unleashes blazing-fast tri-band WiFi 7 speeds up to 18 Gbps. It ensures comprehensive WiFi compatibility for a wide range of devices, from cutting-edge WiFi 6E mobile devices to legacy IoT devices.

Comprehensive MLO Support

Multi-Link Operation (MLO) enables buffering-free connection by intelligently combining and switching between the 2.4 GHz, 5 GHz, and 6 GHz bands. ZenWiFi BT10 is built to be future-proof with all WiFi 7 devices, regardless of the MLO mode they use.

All-new 320 MHz Bandwidth

WiFi 7 introduces ultrawide 320 MHz channel bandwidth in the 6 GHz band, doubling data transmission capacity. This allows for significantly more simultaneous transmissions at the fastest possible speeds.

20% More Efficient with 4K-QAM

Compared to 1024-QAM with WiFi 6/6E, 4096-QAM (Quadrature Amplitude Modulation) allows each signal to more densely incorporate larger amounts of data, delivering up to 20% more efficient data transmission.

AiMesh Made Smarter with AI

ZenWiFi BT10 harnesses the power of WiFi 7 and next-gen Smart AiMesh technology to deliver wider coverage, a more stable and secure network and a feature-rich network experience – all under one network name for your entire smart home.

AI-Powered Mesh Backhaul

Smart AiMesh backhaul intelligently leverages WiFi 7 Multi-Link Operation, automatically aggregating or switching across multiple bands for optimized performance and low latency.

Extendable 10G Connectivity

Experience lightning-fast speeds and robust reliability with our 10 Gbps wired mesh backhaul. With dual 10 Gbps ports, you can extend the 10 Gbps wired backhaul between mesh nodes for strong, seamless connectivity, ensuring your entire home network stays connected and ready for the future.

Efficient Data Prioritization

Unlock optimal data transmission efficiency with ASUS Smart AiMesh. Low-priority packets are directed to the less congested band, while high-priority packets enjoy lightning-fast MLO transmission with optimal resource allocation.

Values Beyond Extension

AiMesh goes beyond just extending coverage or seamless roaming. It works with all compatible ASUS routers, offering easy management, advanced security and smart home features across your entire network.

Unrivaled Coverage and Reliability

With eight internal antennas and ten high-power front-end modules, the ZenWiFi BT10 eliminates WiFi dead zones, delivering consistent coverage in all directions. Efficient heat dissipation also maintains cool and quiet operation for enhanced performance and long-lasting reliability.

Up to 17% Faster CPU Power

Fueled by a powerful CPU and 2 GB of RAM, the ZenWiFi BT10 delivers exceptional processing power. This unleashes advanced features, optimizing your network for smoother 8K streaming, HDR gaming and an enhanced AI network experience.

Dual 10G Ports

The ZenWiFi BT10 includes one 10 Gb WAN/LAN port and one 10 Gb Ethernet LAN port, ready for next-gen entertainment, home studios and ultra-fast 10 Gbps ethernet backhaul.

Versatile WAN options

The ZenWiFi BT10 provides versatile WANs, including a 10 Gigabit WAN/LAN port, a Gigabit WAN/LAN port and an USB WAN for flexible network configurations.

4G LTE & 5G Mobile Tethering

Stay connected anytime with the convenient USB 4G LTE and 5G mobile tethering, even during internet outages or while on the go.

Always Secure Smart Home Protection

ZenWiFi BT10 safeguards your smart home and connected life end-to-end with a powerful combination of cybersecurity solutions and real-time cloud AI/ML data centers powered by Trend Micro™.

Connected with Peace of Mind

Stay protected with top-tier security and privacy offered by a VPN's encrypted connections. No worries about your location and browsing habits, passwords or sensitive data, even when you're using public WiFi.

Hassle-Free Commercial-grade Protection

AiProtection Pro protects your router against ever-evolving online threats like malware, viruses, intrusions and phishing attacks—with just a single tap.

Safeguard Every Device and Everyone

Effortlessly customize WiFi networks tailored to modern smart home needs, ensuring all your devices and your loved ones are protected.

24/7 Network Security Made Easy

AiProtection Pro includes a toolbox for diagnosing network health, fine-tuning settings and receiving on-the-go notifications. Stay vigilant and secure, even when you are away.

One-Tap Security Scan

One-tap router security assessment identifies vulnerabilities in your security settings, helping to prevent malicious activities or connection attempts made by infected devices.

Auto Security Upgrade

Secure your router with incorporated security measures that continuously update files and scans to protect against malware and emerging threats.

Instant Notifications

Receive instant notifications for new device connections to block unknown devices from accessing your network or group new devices into a user profile.

Feature-Packed Smart Home Master SSIDs

ASUS Smart Home Master subnetwork management streamlines the process of creating or connecting to dedicated SSIDs with advanced features like parental controls and VPNs.

IoT Network

Set up and manage all your IoT devices under one secure SSID to provide enhanced security with commercial-grade protection.

Kid’s Network

Create a dedicated SSID just for the kids to easily manage their screen time without needing to configure each device individually.

VPN Network

Connect to your preferred VPN service with a single click through a dedicated subnetwork.

Safeguard the Internet for Your Loved Ones

Advanced family protection and parental controls empower you to nurture a balanced digital life for you and your kids, all without subscriptions.

Powerful Management

The ASUS Router mobile app with its intuitive interface makes managing your mesh WiFi system simple right from your smartphone. Simply follow the on-screen directions, and you will be up and running in no time!

Description

Specification

Type: Cable Router
Connectivity: Wireless
Wi-Fi Rating: BE18000
Max Single Band Wi-Fi Rate: 11529 Mbps
Max Wired Transfer Rate: 10 Gbps
Bands: Tri Band
Signal Rate: 2.4GHz: up to 688 Mbps
5GHz: up to 5764 Mbps
6GHz: up to 11529 Mbps
Interface(s): 1 x 10G WAN/LAN
1 x 10G LAN
1 x GB WAN/LAN
1 x USB 3.0
Standards: IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
WiFi 6E (802.11ax)
WiFi 7 (802.11be)
IPv4
IPv6
Frequency: 2.4GHz / 5GHz / 6GHz
Button(s): "WPS button, Reset button, Power switch"
Power Supply: AC Input : 110V~240V(50~60Hz)
DC Output : 12V with max. 3A current
Antenna(s): 8 x Internal Antennas
Dimensions: 159 x 72 x 186 mm
Wireless Functions: Wireless Router Mode
AiMesh Node Mode
Access Point Mode
OFDMA
4096-QAM high data rate
20/40/80/160/320 MHz bandwidth
MU-MIMO
UTF-8 SSID
WiFi MAC Address Filter
Wireless Scheduler
Airtime Fairness
RADIUS Client
Universal Beamforming
Explicit Beamforming
Security: "AiProtection
VPN
WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise
WPS
Lets Encrypt
DNS-over-TLS
Security Scan
Firewall"
DHCP: DHCP Server
Port/NAT Forwarding: Port Forwarding
VPN Support: Instant Guard
VPN Client L2TP
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Management: ASUS Router mobile app
Dynamic DNS: DDNS
USB Application: 4G / 5G Auto Mobile Tethering
HDD Hibernation
Safely Remove Disk
Download Master
AiDisk
Media Server
Time Machine
Samba Server
FTP Server
Shared Folder Privileges
Additional Features: See Overview
Package Contents: ZenWiFi BT10 Routers
RJ45 cable
Power adapters
Warranty card
Quick start guide
Package Type: Retail
Package Weight: 3.2140 kg
Warranty: 3 Years
#Hide#Wireless Standard: Wi-Fi 7 (802.11be)
#Hide#Mesh Wi-Fi Support: Yes (Mesh Wi-Fi)
